BFO Select
1/4 in. Male x 1/8 in. Female - NPT Threaded - Hex Bushing - 304/304L Stainless Steel - 3000# Forged Pipe Fitting - A/SA182
(No reviews yet)
Write a Review
- SKU:
- 3009-A
- Availability:
- Available
- Weight:
- 0.02 LBS
Description
Specifications / Applications:
- Forged stainless steel material conforms to ASTM A182 grade F304/304L - F316/316L
- Forged stainless steel fitting dimensions conform to ASME B16.11
- NPT threads conform to ASME B1.20.1
- Socket weld fittings conform to ASME B16.11
- Forged stainless union conform to MSS SP-83
- Forged stainless outlets conform to MSS SP-97
- Forged stainless socket weld inserts conform to MSS SP-79
- Manufacturing facility is ISO 9001:2008
- MTRS and COC are available
| Application: | Air, Hydraulic Fluid, Natural Gas, Oil, Steam, Water |
| Pipe Fitting Material: | 304/304L Stainless Steel |
| Specific Fitting Shape: | Hex Bushing |
| Fitting Schedule/Class: | Class 3000 |
| Fitting Connection Type: | Male NPT (larger size) x Female NPT (smaller size) |
| Standards: | ASME A182; ASME B16.11; ASME B1.20.1; ISO 9001:2008 |
| Pressure Level: | High Pressure (1000-3000 psi) | Includes Pre-Applied Thread Sealant: | No |
| MTRS / COC Available | Yes / Yes | For Use with Pipe Schedule: | 80 |
PDF / Specs / Brochure
