BFO Select
2-1/2 in. Male x 2 in. Female - NPT Threaded - Hex Bushing - 316/316L Stainless Steel - 3000# Forged Pipe Fitting - A/SA182
- SKU:
- 3026-U
- Availability:
- Available
- Weight:
- 1.30 LBS
Description
Specifications / Applications:
- Forged stainless steel material conforms to ASTM A182 grade F304/304L - F316/316L
- Forged stainless steel fitting dimensions conform to ASME B16.11
- NPT threads conform to ASME B1.20.1
- Socket weld fittings conform to ASME B16.11
- Forged stainless union conform to MSS SP-83
- Forged stainless outlets conform to MSS SP-97
- Forged stainless socket weld inserts conform to MSS SP-79
- Manufacturing facility is ISO 9001:2008
- MTRS and COC are available
Application: | Air, Hydraulic Fluid, Natural Gas, Oil, Steam, Water |
Pipe Fitting Material: | 316/316L Stainless Steel |
Specific Fitting Shape: | Hex Bushing |
Fitting Schedule/Class: | Class 3000 |
Fitting Connection Type: | Male NPT (larger size) x Female NPT (smaller size) |
Standards: | ASME A182; ASME B16.11; ASME B1.20.1; ISO 9001:2008 |
Pressure Level: | High Pressure (1000-3000 psi) | Includes Pre-Applied Thread Sealant: | No |
MTRS / COC Available | Yes / Yes | For Use with Pipe Schedule: | 80 |
